Showing 211–216 of 216 results
-
Measuring Tools
UNI-T INSULATION RESISTANCE TESTER (UT501A)
UT500 series insulation testers are used to measure the insulation resistance of electrical equipment and household appliances. This is done by measuring the insulation resistance between electrical circuits or between circuits and ground. UT500 series can measure insulation resistance, AC Voltage, low resistance, PI (Polarization Index) and DAR (Dielectric Absorption). These are dieal tools for ensuring transformers, genera-tors, high voltage motors, capacitors, cables, arresters and other electrical equipment that can oprate in a safe and accurate manner.
SKU: n/a -
Measuring Tools
UNI-T POCKET SIZE MULTIMETER (UT120C)
DC voltage (V) 600V ±(0.8%+1)
AC voltage (V) 600V ±(1.2%+3)
DC current (A) 400mA ±(1%+3)
AC current (A) 400mA ±(1.5%+5)
Resistance (Ω) 40MΩ ±(1%+2)
Capacitance (F) 100μF ±(4%+3)
Frequency (Hz) 10MHz ±(0.5%+3)
Features
Display count 4000
Auto range
Duty cycle 0.1%~99.9%
Diode √ √
Auto power off Around 30 minutes
Continuity buzzer
Low battery indication ≤2.4V
Data hold
Relative mode
Input impedance for DCV Around 10MΩSKU: n/a
