Measuring Tools
Showing 31–43 of 43 results
-
Measuring Tools
UNI-T BATTERY TESTER (UT673A)
Certificates CE,FCC,RoHS
12V battery test 7~16V DC√
12V/24V cranking system test 7~30V DC√
12V/24V charging system test 7~30V DC√
Battery type Ordinary lead acid battery,AGM flat plate battery,AGM spiral battery,GEL battery, EFB battery
Battery capacity 3~250Ah√
Battery standard and range CCA: 40~2000; BCI: 40~2000; CA: 40~2000; MCA: 40~2000; JIS: 26A17~245H52; DIN: 40~1400;
IEC: 40~1400; EN: 40~2000; SAE: 40~2000; AH: 3~250AHSKU: n/a -
Measuring Tools
UNI-T DIGITAL CLAMPMETER (UT202+
UT200+ series digital clamp meters are designed according to EN61010-2010 CAT II 600V/CAT III 300V, featuring overload protection, high reliability, high safety and high accuracy. These meters can be used to measure high-voltage frequency, temperature, AC/DC current, etc.
SKU: n/a -
Measuring Tools
UNI-T INSULATION RESISTANCE TESTER (UT501A)
UT500 series insulation testers are used to measure the insulation resistance of electrical equipment and household appliances. This is done by measuring the insulation resistance between electrical circuits or between circuits and ground. UT500 series can measure insulation resistance, AC Voltage, low resistance, PI (Polarization Index) and DAR (Dielectric Absorption). These are dieal tools for ensuring transformers, genera-tors, high voltage motors, capacitors, cables, arresters and other electrical equipment that can oprate in a safe and accurate manner.
SKU: n/a -
Measuring Tools
UNI-T POCKET SIZE MULTIMETER (UT120C)
DC voltage (V) 600V ±(0.8%+1)
AC voltage (V) 600V ±(1.2%+3)
DC current (A) 400mA ±(1%+3)
AC current (A) 400mA ±(1.5%+5)
Resistance (Ω) 40MΩ ±(1%+2)
Capacitance (F) 100μF ±(4%+3)
Frequency (Hz) 10MHz ±(0.5%+3)
Features
Display count 4000
Auto range
Duty cycle 0.1%~99.9%
Diode √ √
Auto power off Around 30 minutes
Continuity buzzer
Low battery indication ≤2.4V
Data hold
Relative mode
Input impedance for DCV Around 10MΩSKU: n/a
